6FOOT Pan Mixer

6 Foot Pan Mixer – Typical Specifications Capacity

• Pan Diameter: 6 ft (1800 mm)
• Batch Capacity: 500–750 kg per batch
• Pan Volume: 900–1200 Liters

Construction

• Pan Material: Mild Steel (MS) or SS304 (optional)
• Mixing Blades: Heavy-duty wear-resistant alloy steel
• Frame: Heavy fabricated steel structure
• Discharge: Manual or pneumatic bottom discharge gate

Drive System

• Main Motor: 10–15 HP
• Gearbox: Heavy-duty planetary or helical gearbox
• Pan Speed: 18–25 RPM
• Power Supply: 415 V, 3 Phase, 50 Hz

Approximate Dimensions

• Overall Length: 7–8 ft (2.1–2.4 m)
• Overall Width: 7–8 ft (2.1–2.4 m)
• Overall Height: 5–6 ft (1.5–1.8 m)

Approximate Machine Weight

• MS Model: 1200–1800 kg
• SS Model: 1500–2200 kg

Recommended Installation Space

• Minimum Floor Space: 12 ft × 12 ft (3.7 m × 3.7 m)
• Recommended Working Area: 15 ft × 15 ft (4.6 m × 4.6 m)
• Minimum Room Height: 10 ft (3.0 m)

Standard Features

• Heavy-duty mixing blades with adjustable scrapers
• High-torque geared drive
• Uniform and fast mixing
• Robust steel frame for continuous operation
• Easy discharge and cleaning
• Low maintenance design

Applications

• Fly ash brick manufacturing
• Paver block production
• Concrete and mortar mixing
• Refractory materials
• Ceramic and mineral processing
• Chemical powder mixing

Typical Mixing Time



• 3–8 minutes per batch, depending on the material and moisture content.
